| Yamaha Fascino 125 Fi Hybrid Drum General Features | |
|---|---|
| Engine Type | Air-cooled, 4-stroke, SOHC, 2-valve |
| Top Speed | - |
| Engine Capacity | - |
| Starting | - |
| Brakes | Drum |
| Gear Box | V-belt automatic |
| Fuel Tank Capacity | 5.2 L |
| Tyre Type | Tubeless |
| Yamaha Fascino 125 Fi Hybrid Drum Standard Features | |
|---|---|
| Brakes | Drum |
| Pass Switch | |
| Cooling System | - |
| ABS | - |
| CBS | - |
| Ebs | - |
| Body Graphics | |
| Carry Hook | - |
| Shutter Lock | 1 |
| Yamaha Fascino 125 Fi Hybrid Drum Engine & performance | |
|---|---|
| Engine Type | Air-cooled, 4-stroke, SOHC, 2-valve |
| Displacement | 125 |
| Mileage | - |
| Bore | 52.4 mm |
| Stroke | 57.9 mm |
| Compression Ratio | 10.2:1 |
| Maximum Power | 8.2 PS @ 6500 rpm |
| Maximum Torque | 10.3 Nm @ 5000 rpm |
| Starting | Kick and Self Start |
| Maximum Speed | - |
| Yamaha Fascino 125 Fi Hybrid Drum Transmission | |
|---|---|
| Gear Box | V-belt automatic |
| Clutch | - |
| Transmission Type | Automatic |
| Yamaha Fascino 125 Fi Hybrid Drum Fuel | |
|---|---|
| Fuel Capacity | 5.2 L |
| Supply System | - |
| Fuel Reserve | - |
| Fuel Gauge | - |
| Digital Fuel Gauge | - |
| Yamaha Fascino 125 Fi Hybrid Drum Brake | |
|---|---|
| Brakes | Drum |
| Front Brake | Drum |
| Rear Brake | Drum |
| Yamaha Fascino 125 Fi Hybrid Drum Tyre Size | |
|---|---|
| Tyre Size | Front :- 90/90-12 Rear :-110/90-10 |
| Radial Tyres | - |
| Yamaha Fascino 125 Fi Hybrid Drum Wheel Size | |
|---|---|
| Wheel Size | Front :-304.8 mm, Rear :-254 mm |
| Wheel Base | 1280 mm |
| Yamaha Fascino 125 Fi Hybrid Drum Chassis and Suspension | |
|---|---|
| Bike Suspension | - |
| Yamaha Fascino 125 Fi Hybrid Drum Frame | |
|---|---|
| Chassis/ Frame | - |
| Yamaha Fascino 125 Fi Hybrid Drum Electrical | |
|---|---|
| Ignition | TCI (Transistor controlled ignition) |
| Battery Type | Lead Acid |
| Head Lamp | - |
| Tail Lamp | - |
| Turn Signal Lamp | Bulb |
| Yamaha Fascino 125 Fi Hybrid Drum Exterior Dimensions | |
|---|---|
| Length | 1920 mm |
| Height | 1150 mm |
| Width | 685 mm |
| Ground Clearance | 145 mm |
| Saddle Height | 780 mm |
| Kerb Weight | 99 kg |
| Total Weight | - |
| Weight Carrying Capacity | - |
| Chassis/ Frame | - |
| Wheel Base | 1280 mm |
